The Automatic Sand Filter 1044 (Cabinet Type) integrates a multi-layer sand filtration system into an easy-to-install, fully automatic cabinet. Featuring Bypass Flow Technology (BFT) and microprocessor-controlled operation, it efficiently removes suspended solids, turbidity, and coarse particles to protect downstream equipment like water softeners, RO units, and appliances.With a 10″ × 44″ FRP tank, it holds around 30 L of sand media plus 46 L of resin, handling up to 3,000 LPH and supporting around 69,000 L of treated water based on 200 ppm hardness before requiring regeneration . Its powerful cabinet package includes a brine tank, sampler valve, float assembly, and operates at 0.15–0.6 MPa, making it well-suited to bungalows, standalone homes, and small commercial setups
Easy to install and ready to use
Elegant designed, cabinet type water softener
Fully automatic microprocessor-controlling operation
Display - current time, remaining soft water & current flow
Inbuilt brine tank, brine valve and float assembly
BFT Technology helps to make fully automated operation with pump, water level controller and Softener
Incorporated with pressure relief SV and sampling valve
Can be use before and after soft water storage tan
Can be use for individual Bungalow
Property | Value |
Max. Flow Rate | 3000 LPH |
OBSA (Basis on 200 ppm) | 69000 Ltr |
OBR (Basis on 200 ppm) | 11500 Ltr |
Resin Tank Volume | 50 Ltr |
Resin Quantity | 46 Ltr |
Salt Tank Volume | 73 Ltr |
Salt Required / Regeneration | 7 kg |
Salt Qty.(OBSA) / No's of Regeneration | 42 kg / 6 |
Working Pressure | 0.15 - 0.6 MPA |
Inlet-Outlet Size | 1" |
Dimensions in mm | L390 X W580 X H1310 |
